Technical description
The stable manure collector 1 according to this design consists of a frame 2 with sidewalls and a bottom 9, which together form a collection space of about 110 cm in width (see Fig. 1). The picking blade 3 is fastened to the front crossmember 7 by means of screws, its shape and angle provide sufficient dynamic impact to the collected matter when moving the device. With the lifting mechanisms 4 and 4', the support wheels 5 and 5' can be extended and the level of the picking blade 3 can be adjusted to the required height. The device is connected to a towing vehicle by a tow bar 6, which is fitted with a towing attachment 8 in the front. In order to obtain the optimum position of the tow bar 6 between the vehicle and the frame 2, the device is provided with holes for connecting the bar at several height levels. The weight of the device is 45 kg.
